MODEL 207A AND 207A-1
OPERATION MANUAL
Doc. No. 740044
Rev F
SECTION IV - SYSTEM FUNCTIONS
4.9 GLOSSARY (continued)
ROT DLY = Rotation or travel start delay time
RPM = Revolutions per minute
SKT = Socket type weld
SP = Special material and weld type.
SS = Stainless steel
SYS HOURS = System hours indicate total power-on time.
TEMP = Power supply internal temperature
TI = Titanium
T/TS = Tube to tubesheet
# = Weld schedule number
* = Indicates that more information is available
4.10 GLOSSARY OF DISPLAY TERMS - The M-207A displays contain many terms
that do not relate directly to a function or sequence. The following is a listing of
those terms:
AMIWELD = Name, type and revision of software
ARC GAP = Distance needed between electrode and weld
ARC HOURS = Total hours system has been welding
BAD START = Problem has occurred with RF start.
CALCULATE = Function calculates RPM or tungsten length.
CANCEL = Ends step without storing or completing
COPY = Allows a schedule to be copied with a new #.
CREATE = For creating a new weld schedule
DATE RESET = Resets date function
DELETE = Used to delete a weld schedule from memory
INVALID NUMBER = Can appear under the following conditions:
1. Attempting to CREATE a weld schedule that already
exists.
2. Selecting a weld schedule that does not exist.
MODE LOCK = Screen cannot be changed. Weld schedule (if selected)
will be locked in.
MODIFY = Used to permanently change a weld schedule.
OPERATE/WELD SELECT = Operate mode only, cannot program
OVERRIDES = Ability to change a value temporarily.
PROGRAM/OPERATE = Ability to program or operate.
RING = Insert ring is used for filler material.
4.16
