Arcan CP401 - Parts List

CP401 Operation Manual 2
PARTS LIST
Press Frame - 1
Press Bed - 1
Press Feet - 2
Z Bar - 1
1/2"-13 x 1-1/2"
Hex Head Bolts - 10
1/2" Nuts - 10
Washers - 10
1-1/4" x 14" Press Pins - 4
Air Motor
Pump and Ram - 1
Pump Extension Handle - 1
1" x 3" x 14"
Press Plates - 2
Accessory only -
Not needed for assembly
Pushing Adapter - 1
Accessory only -
Not needed for assembly
Bearing Shield - 1
Accessory only -
Not needed for assembly
ESTIMATED ASSEMBLY TIME: 30 MINUTES
Examine box contents, then proceed with the following instructions.
TOOLS NEEDED
3/4" and 9/16" sockets and wrenches
ACCESSORIES
