ASSEMBLY INSTRUCTIONS CONTINUED
Stand unit upright Slide bed above holes and hold in place
Secure pins underneath bed, one at a time
1
2
6
WARNING
Pins must be COMPLETELY through BOTH SIDES of frame.
7
Let bed rest on inserted pins Place 3rd and 4th pin on each side Secure pins completely through bed and frame.
3 4
WARNING
ALL FOUR (4) pins must be COMPLETELY through BOTH SIDES
of frame in order to operate press.
CP401 Operation Manual 5
