Archgard OPTIMA 22 - Page 35

OPTIMA 22 35
REPLACEMENT PARTS LIST FOR THE ARCHGARD OPTIMA 22
Item # Item Description Qty Unit
Replacement parts for BBAY-22 Bay Door
300-0031 Magnet Pull 2 EA
307-0053 Glass, 6mm Tempered (Middle Piece) 1 EA
307-0052 Glass, 6mm Temp (Side Piece) 2 EA
314-0006 Flat Gasket 65 IN
308-0111 Robertshaw Hi-Lo Extension 3” Knob 1 EA
308-0112 Robertshaw On/Off Extension 3” Knob 1 EA
GMDS-22
Optional Gold Bay Window Strips (Full Set)
Includes top & bottom trim pieces
1 EA
Optional Surround Trims
BEDTK-22 Black Trim for ESK & DSK-22R surround 1 SET
BLTK-22 Black Trim for LSK-22R surround 1 SET
GEDTK-22 Gold Trim for ESK & DSK-22R surround 1 SET
GLTK-22 Gold Trim for LSK-22R surround 1 SET
PEDTK-22
Pewter Trim for ESK & DSK-22R surround 1 SET
PLTK-22 Pewter Trim for LSK-22R surround 1 SET
312-0021 2-inch Flex Liner - 35 feet 1 EA
LK-22 Optional 2-inch Flex Liner Kit - Consists of:
313-0011 2-inch Spun Reducer - 3” x 2” 2 EA
300-0011 Self-Tapping Hex Head Screws - ¼” 12 EA
