Service Data and Specifications
INSPECTION AND ADJUSTMENT
Item
Engine model
Intake
Valve clearance
(Hot) mm (in)
Exhaust
Fan belt deflection mm (in)
Applied pushing force
N (kg, lb)
Engine oil capacity
(US qt. lmp qt)
With oil filter
Without oil filter
Engine compression pressure
kPa (bar, kg/cm2, psi) rpm
Standard
Minimum
Spark plug
Type
Gap mm (in)
Distributor
Air gap mm (in)
High tension cable resistance
Ignition timing idle speed
B.T.D.C. degree/rpm
Max. engine speed under no load
rpm
Max/ engine speed under load
rpm
H15 H20-II H25
0.38 (0.015)
1 - 13 (0.43 - 0.51)
98 (10, 22)
3.8 94, 3-3/8)
3.5 (3-3/4, 3-1/8)
1,275(12.75, 13.0, 185)/300 1,226 (12.26, 12.5, 178)/300 1,275 (12.75,13.0, 185)/300
1.079 (10.79, 11.0, 156)/300 1.030 (10.30, 10.5, 149)/300 1.079( 10.79, 11.0, 156)/300
BP4WES, BP4ES
0.8 - 0.9 (0.031 - 0.035)
0.35 - 0.45 (0.0138 - 0.0177)
Less than 30,000
4° /650 See valve cover label
3,100 - 3,300 2,800 - 3,000
2,500 - 2,900 2,600 - 3,000 2,300 - 2,600
