12
This is the total Amp hours
of all batteries in the bank,
for example, three 300Ah
batteries would be 900Ah.
Amp hours is the amount of
energy charge in a battery
that enables one ampere of
current to flow for one hour.
This information is location
on a label on the battery or
manufacturer’s website.
This information would be
found on the label of your
battery. Lithium Ion batteries
can be subjected to much
higher charge currents.
Set the parameter of 12v,
24v, 36v, or 48v
This enables the regulator to
account for losses in your system.
The default number will be 1.
You can fine tune this to match
the current measurement from
an existing system if it does not
match. For example, your Victron
Smart Shunt that may show a
dierent measurement.
Your Shunt Rated Amps
will be on your shunt.
Most shunts are
500a/50mV.
Your Shunt Rated mV
(millivolts) will be
visible on your shunt.
Click NEXT
to continue.
INSTALLATION
