6
For state of charge, the shunts must be
connected. Suggestion on shunt placement.
You have set up measuring instruments on the only Regulator that monitors 1) BOTH
Batteries and Alternator inputs AND 2) can measure State of Charge (SOC).
Positive side shunts are typically used with case ground alternators.
Congratulations!
INSTALLATION
6
