Instruction manual – AQ 110 arc protection unit 2 (65)
Revision
1.2
Date
July 2011
Changes
- Sensor chapter revised. (Fiber pictures and point
sensor connections).
- Standard Arc System chapter revised. (e.g. scheme 0a
added)
- Dipswitch definition updated (e.g. HSO latch/non-
latch)
- LED description revised, (current channels LEDs will
not blink during the auto-configuration.)
- Partly AQ110F information added.
- Dimensions and installation chapter, the depth of the
unit is changed from 170mm to 175mm.
- Casing and dimensions section, the unit size and the
size with package have been added.
Revision
1.3
Date
April 2012
Changes
- AQ SAS™ chapter is removed from manual.
Revision
1.4
Date
July 2012
Changes
- Scheme Select Dipswitch Settings chapter is added.
- The point sensor max. wiring length is up to 200 meters.
System self-supervision chapter is revised.
Revision
1.5
Date
May 2019
Changes
- Move scheme selection content to dipswitch setting,
refer to chapter 3.5.
- Technical data update
- Add application example, refer to chapter 6.
