ARCTIC WIND ATMSL181 - Door Handle Installation

6
2.2 DOOR HANDLE INSTALLATION
Precautions shall be taken to prevent the handle from falling and causing any personal injury.
PARTS DIAGRAM:
c Bolt d Bolt hole e Handle screw f Screw hole cap
INSTALLATION PROCEDURES:
1. Take out bolt c from accessory bag, use the cross screwdriver to put the bolt c into the bolt hole d of
refrigerator door.
2. Put the handle on the door onto the bolt c and make sure the handle makes close contact with the door surface.
3. Secure the handle by rotating the screw e to the end, then shake the handle to verify that it is fi xed tightly
4. Put the cap f on the screw hole to complete the installation.
LIST OF TOOLS TO BE PROVIDED BY THE USER:
Cross Screwdriver
À
À
The hole
The screw
(The picture above is for reference only. The actual confi guration will depend on the physical product or statement by the distributor.)
