View of the Appliance
Cooling
• Evaporator is contained in the interior walls of the Appliance. Once it starts operating, frost appears on
the interior walls and it cools down gradually.
Heat Radiation
• Heat radiation is performed by the block condenser in the compressor compartment. While the
Appliance is cooling down, the block condenser gets hot and heat is radiated by forced air.
Shelves
• Every shelf can be moved up and down with a pitch of 13mm. Place the 4 brackets at the desired
height.
Access Port
• There is a porthole in the upper left corner of the interior rear wall of the Appliance, where you can
insert temperature sensors. (The inside diameter is 20mm, and the exterior opening is sealed with a
rubber plug.)
Operation Panel Cover
• The operation panel is protected by an acrylic resin cover.
Locking handle
Lock
Access Port (Back side)
Operation Panel
Adjustable Foot
Air Vents (Left side and top)
Handle
6
