ARDES AR5A107D - Electrical Connection; Maintenance

16
Maintenance
Before carrying out the regular cleaning operations and before replacing
the lamp turn off the fan and disconnect it from the electrical supply.
For external cleaning use a soft and dry cloth.
DO NOT dip the device in water, or splash it with any other liquids.
DO NOT use solvents or any other chemical products for cleaning it.
ELECTRICAL CONNECTION:
YELLOW/GREEN
BLACK
WHITE
BLUE
FAN
L
N
220-240V
50Hz
~
Instructions for use
The ceiling fan is provided with 2 pull cord chain and switch for reversible
function that allows to invert the rotation of the blades.
The pull cord chains control the light and the speed; the function of the
pull cord chains are as below:
Speed pull cord chain: you can select maximum speed (pulling
the chain once), medium speed (pulling the chain twice) or
minimum speed (pulling the chain thrice).
Light pull cord chain: you can turn on or off the light of the fan.
