Unscrew the screws (24) from the supporting tubes (15). Place the
supporting tubes (15) into the holes of the base (16) making sure that
the holes on the bottom of the support tubes and the holes in the tube
housings on the base are coincident. Ensure the supporting tubes (15)
on the base (16) by using the 4 screws (24) previously unscrewed.
Place the weight of the base (17) under the base (16). NB: the weight
of the base has a at face and a curved face; the at side must placed
against the base. Fix the weight of the base (17) using the 4 screws
supplied (25).
Loosen the screws (13), insert the main body (12) on the support tubes
(15) and x it by tightening the xing screws (13).
Place the humidier main body (20) in its housing on the base (16).
Fix the misting plate (2) in the front grid (3) making sure that the logo in
the center of the plate is horizontal, parallel to the oor and ensure it by
using the screw provided (4).
Unscrew the lock ring of the back grille (7) by rotating it counterclockwise,
from the motor shaft (9).
Insert the back grille (8) on the motor shaft (9) so that the grip is pointed
upwards and the holes/pins match. Then x it with the grille lock ring (7)
by rotating it clockwise.
Insert the fan (6) on the motor shaft (9) and x it by rotating the lock ring
(5) counterclockwise.
Open the clip of the front grille (3) and place it on the back grille (8)
making sure that the logo in the central stud is placed horizontal, parallel
to the oor.
Find the proper position to tighten the safety screw (1).
Fill up the tank (19) following the instructions from paragraph “HOW TO
FILL UP THE TANK” and place it on the main body of the humidier (20).
Connect the misting tube (22) to the misting adjustment knob (2) and in
the lower part insert the the humidier cap (23) on the tank (19).
The assembly procedure is complete.
