OPERATING AND MAINTENANCE INSTRUCTIONS
6.5 hp 4-Stroke Engine
6.5 HP VIPER ENGINE PARTS LIST
REF
NO.
PART
NO. DESCRIPTION QTY.
1 64686 MUFFLER KIT 1
2 64304 GAS TANK 1
3 64283 HOUSING, AIR CLEANER 1
4 64237 FAN HOOD ASSEMBLY 1
5 64285 BASE, AIR FILTER 1
6 64279 COVER, AIR CLEANER 1
7 64308 CARBURETOR ASSEMBLY 1
8 64207 STUD BOLT, M6 X 113 2
9 64309 GASKET, AIR CLEANER 1
10 64204 AIR DUCT 1
11 64732 NUT, FLANGED M6 2
12 64291 NUT, FLANGED M8 2
13 64274 NUT, FLANGED M14 1
14 64733 SCREW, FLAT HEAD 2
15 64286 HOLDER, AIR FILTER 1
16 64280 AIR FILTER ELEMENT 1
17 64281 WASHER 1
18 64278 WING NUT 1
19 64294 GASKET, EXHAUST 1
20 64182 DIPSTICK ASSEMBLY 2
21 4352 KEY 1
22 6327 GAS CAP W/ PACKING RING 1
REF
NO.
PART
NO. DESCRIPTION QTY.
25 64277 FLYWHEEL 1
26 64276 FAN, FLYWHEEL 1
27 64275 STARTING FLANGE 1
28 64273 IGNITION COIL ASSEMBLY 1
29 64269 BOLT, M6 X 25 FLANGED 2
30 6272 BOLT, M6 X 18 FLANGED 4
31 6263 BOLT, M6 X 12 FLANGED 3
32 64212 SPARK PLUG 1
33 64250 RECOIL STARTER ASSEMBLY
(INCLUDES PULL-START HANDLE)
1
34 64305 GASKET, INLET 1
35 64306 CONNECTING BLOCK 1
36 64307 GASKET, CARBURETOR 1
37 6204 OIL DRAIN PLUG 2
38 64157 WASHER 2
39 64249 PULL-START HANDLE 1
