Ardo A 800 - Control Panel Description

SM1
DESCRIPTION OF THE WASHING MACHINE - CONTROL PANEL
7
1 2 3 4 5 6 7 8 9 10 11
1 2 3 12 6 5 13 8 9 10 11
1. – table of programmes
2. – detergent compartment
3. – temperature limit button
4. – no-drain button
5. – economy was button
6. – no-spin button
7. – main on/off button
8. – thermostat dial
9. – spin rpm control dial
10. – programmer dial
11. – machine “on” indicator light
12. – additional rinse button
13. – 500/800 spin speed button
14. – door
15. – filter
16. – adjustable feed
17. – top cover
18. – drum
