Arduino Mega2560 User Manual

Lesson 4: Bluetooth Imitation Robot Car
In this lesson, we will use Mobile to control our robot car and make an imitation
driving. Since is a mock driving, we will use a virtual steering wheel and gear in our
APP to imitate their counterparts in real car.
In this lesson,Mecanum Omni wheel will allows robot car make omni-directional
movement( parallel shift to left and right).
OSOYOO Mecanum Wheels Robotic Car Chassis x1(2x left-wheels/2x right-wheels and 4x motor)
OSOYOO Mega2560 board fully compatible with Arduino
OSOYOO V1.0 Wifi Shield x 1
OSOYOO Model X motor driver x 2
OSOYOO HC02 bluetooth module
OSOYOO Battery box x 1
18650 Batteries(3.7V) x 2
You must complete lesson 1 (assembling the car) before you continue on with this
lesson.No need change anything, just keep the hardware wire connection as it is.
STEP1: Connect B_TX and B_RX to D19 and D18.
(Note: You need split 2 pcs of male-to-female jumper wires from our 10-pc jumper wire
bundle. Any color from the bundle will be ok. The rest of 8 pcs wires are as spare parts
for potential broken or damaged wires.)

Arduino Mega2560 Specifications

General

Microcontroller	ATmega2560
Operating Voltage	5V
Input Voltage (recommended)	7-12V
Input Voltage (limit)	6-20V
Digital I/O Pins	54 (of which 15 provide PWM output)
Analog Input Pins	16
DC Current per I/O Pin	20 mA
DC Current for 3.3V Pin	50 mA
Flash Memory	256 KB of which 8 KB used by bootloader
SRAM	8 KB
EEPROM	4 KB
Clock Speed	16 MHz
Length	101.52 mm
Width	53.3 mm
Weight	37 g
