Areva FP 73 - Page 17

13
Ep Ep
L
H
h
l
Front view lay-out (front face)
Un < 24 kV 24 kV < Un < 36 kV
Ep (mm) 210 250 300 350 400
In
< 2,500 A
L (mm)
680 740 840 940 1040
> 2,500 A
L
(
mm
)
700 740 840 940 1040
< 1,250 A
H ()
841 841 841 931 -
> 1,250 A < 2,500
A
H (mm)
1013 1013 1013 1013 1013
> 2,500 A
1060 1060 1060 1060 1060
< 1,250 A
h ()
476 476 476 566 -
> 1,250 A < 2,500
A
h (mm)
595 595 595 595 595
> 2,500 A
595 595 595 595 595
< 1,250 A 470 470 470 470 470
> 1,250 A < 2,500
A
l (mm)
-
543 543 543 543
> 2,500 A
-
600 600 600 600
