Section 9. TECHNICAL DATA
9.1 Ratings – auxiliary supply
Nominal Operative
KITZ 101
110/240V ac 87– 265V ac 50/60Hz
KITZ 102
24/125V ac/dc 19–150V dc
50–133V ac 50/60Hz
48/250V ac/dc 33 – 300V dc
87– 265V ac 50/60Hz
9.2 Burden – auxiliary supply
KITZ 101 (ac) <3VA
KITZ 102 (ac) <5VA
(dc) <3W
9.3 Fuse Ratings
KITZ 101
Maximum recommended fuse rating (HRC or time lag type) is 6A.
Internal fuse rating is 1.6A/T 250V, 5x20mm.
KITZ 102
Maximum recommended fuse rating is 16A.
9.4 Accuracy
9.4.1 Real time clock (RTC)
RTC drift from setting at 20°C (over range –25°/+55°C) < 8s per 24 hours
Synchronisation Error: Time setting Error ±1.5ms
*
Time Tagging Error: Current RTC Time Error +0 ms/–1ms
* If the RS232 (IEC-870) 10 bit frame format and a data rate of 1200 or
2400 bps are selected, synchronisation error is +2.0/–1.0ms.
9.4.2 Software communication timers
IEC data receive character gap timer: 33 bits +2.0/–0ms
IEC data receive error break timer: 33 bits +2.0/–0ms
IEC data transmit maximum transmit time: 5500 bits +2.0/–0ms
K-Bus data receive character gap timer: 2.0ms +0/–1.0ms
K-Bus data transmit maximum transmit time: 500ms +0/–1.0ms
9.5 Operation indicator
5 light emitting diodes - internally powered.
