ARGENTO OMEGA + - LCD Operation; Display Functions; PAS Level Configuration

19
8. LCD
The EPAC has an LCD for complete control of all the bike’s functions.
Switching on/o
Press and hold the ON button for at least one second to switch the LCD on/o.
Pedal assist system (PAS)
Press the + or + button to increase or decrease the PAS level (pedal assist mode).
The display is pre-configured to oer 5 pedal assisted levels. Level 1 provides minimum
assistance from the motor while level 5 provides the maximum. Level 0 provides no assistance
from the motor.
You can opt for a range of dierent pedal assisted levels when configuring the display: 0-3,
0-5 and 0-9. These options do not modify the maximum assistance provided but only allow a
distribution of the dierent assistance levels.
The table below is provided to show a comparison between the dierent ranges.
3 levels 5 levels 9 levels
0 0 0 No assistance
1 1
2
1 2 3
4
3 5
2 6
4 7
8
3 5 9
+
-
ONM
