ARGENTO OMEGA + - Description of the Bicycle (EPAC); Component Identification

07
3. Description of the bicycle (EPAC)
1. Saddle
2. Seat post
3. Rear wheel padlock
4. Luggage rack with bungee cords (max
15Kg)
5. Rear LED light
6. Rear mudguard
7. Rear wheel
8. Rear mechanical disc brake
9. 36V 250W motor
10. 7-speed Shimano derailleur
11. Motor port
12. Stand (opposite side)
13. Chain
14. Pedal (right)
15. PAS
16. Front wheel
17. Front mechanical disc brake
18. Front fork
19. Front mudguard
20. Front LED light
21. Handlebar tube
22. Handlebar stem
23. Handlebars
24. Bell
25. Brake lever with motor sensor (right)
26. Brake lever with motor sensor (left)
27. 7-Speed Shimano gear shift control
28. LCD
29. Battery lock/release clamp (opposite
side)
30. Li-Ion 36V 10.4Ah battery
31. Battery charger port (opposite side)
32. Frame serial number
18
17
19
21
32
22
23
25
24
27
26
display
29
31
30
16
11
15141312
10
7
8
9
6
2
3
5
4
1
28
