1.Removing the rear panel
1. Remove 6 screws on the left and right sides of the front panel, then remove
the screws fixed on the rear panel.
2. Manually pull the rear panel outward to make sure that the top and bottom
attachment positions of the front and rear panel are
disconnected.
There is a hook in the connection between the front and the
rear panel; be careful when removing.
There is a hook in the connection between the front and the
rear panel; be careful when removing.
