ASSEMBLY INSTRUCTIONS
Open the box and remove the parts of the appliance.
Assembly diagram of the parts
Motor shaft.
Insert the rear grill on the motor shaft
in the proper position.
Screw the nut in order to fasten the
rear grill firmly.
Set the blade on the motor shaft.
Put the outer column into the base and put the lock nut under the base, rotating it in a clockwise direction and ensure it is
fixed
1
2
3
