Engine System Argo Service Manual
Ontario Drive & Gear Limited www.odg.com
PH. (519)- 662-2840 FAX (519)- 662-2421
EN-16
6. Lower the rear of the power pack frame aligning the mounting bolt with the main
frame. Photo EN-28
7. Install the 3rd mid mounting bolt paying close attention to the hardware that is re-
quired along with it. See your illustrated parts manual. Photo EN-29
EN-28 EN-29
On vehicles manufactured prior to serial
number CB17117, ensure that the air intake
duct seal at the radiator, is properly seated
back up against the face of the radiator
assembly. Photo EN-30.
EN-30
8. Reconnect the hose at the brake cool-
ing duct.
9. Perform the servicing procedure, Installing the Muffler and Shroud (Conquest
Models), in section DE of this service guide.
ii. Slip the over flow bottle back into the holder and connect the hose.
On Conquests manufactured prior to CB14963:
i. Reattach the radiator overflow bottle holder at the front of the engine.
On Conquests manufactured from CB14963:
i. Attach the radiator over flow bottle directly to the upper rad bracket installing the 2
required spacers at each mounting bolt. re-insert the overflow hose.
