Please check you have all the fittings listed below
3
Components - Fittings
If you have damaged or missing components, call the
Customer Helpline: 08456 400800 quoting the reference
numbers below
Note: The quantities below are the correct amount to complete the assembly. In some cases
more fittings may be supplied than are required.
A
Wooden dowel (F22) x 7
B
Metal dowel (F901) x 11
C
D
Large locking
nut (F900) x 7
E
G
40mm Screw (F910) x 12
I
L
Small locking
nut (F3) x 4
J
M
9mm Screw (F74) x 4
K
N
9mm Screw (F73) x 8
Drawer runner (F1004) x 4
Knock-in Peg (F171GY) x 16
P
Plastic Nail (F91) x 10
O
Wedgefix (F639) x 4
13mm Screw (F52) x 6
13mm Screw (F63) x 6
Q
Handle (F262) x 3
H
25mm Screw (F50) x 8
JR
CR Runner
(F903) x 1
CL Runner
(F904) x 1
DR Runner
(F905) x 1
DL Runner
(F906) x 1
a
R
b
R
c
d
R
CL
CR
F
Nail (F51) x 14
45mm Screw (F65) x 3
Ruler - Use this ruler to help correctly identify the screws
mm 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 160 170
