Step 8
Step 9
I
8
I
I
I
6
5
Attaching panels
Two people are needed
here.
Position upright small 6
onto bottom 5 and small
horizontal 8.
Insert two Large locking
nuts I into upright small
6 and small horizontal 8
where shown.
Use a screwdriver to turn
locking nuts I clockwise to
lock.
H
H
H
6
Unfinished
back edge
8
Assembly Instructions
Step 7Step
Insert locking screws
Screw 24mm locking
screw H into upright
small 6.
M
M
I
I
P
P
P
H
H
H
H
H
H
M
F
H
1
1
P
1
Insert fittings
Screw 24mm locking
screw H into left side 1.
Note: Insert 24mm
locking screw H as far
as shown.
Do not over tighten.
Screw hinge back P
onto upright 1.
Attach hanger rail
support M using 12.5mm
screw F onto left side
2.
H
M
1
F
I
Warning: Do not use an electric screwdriver to attach the
hinges as this can weaken the fixing.
