Assembly Instructions
Step 1.22
Place one of the backs
7
into the rabbet on the
top
1
and onto the post
4
and the large
divider
1
.
!
Important!
Make sure the
angle between
the top
1
and the post
4
is 90° when the back
7
is
attached.
The back
7
must cover
exactly half of the divider
5
. Note the distance.
Fix the back
7
to the
top
1
, the post
4
and
the back rail
11
using
nails
Di
.
Use a small hammer.
350264-14
13
1.2 x 15mm Nail x
Di
18
Distribute equally !
Distribute equally !
7mm from edge of Divider !
5
7
11
4
1
Di
Di
Di
Di
