Argos 2587356 - Page 18

Assembly Instructions
Step 2.6
!
Important!
Make sure the
angle between
the drawer front
13
and
the drawer sides
14
is 90°
before the drawer bottom
16
is xed using
Fi
as
shown.
To adjust the angle between
the drawer sides and the
fronts push the tting
Fi
sidewards. See details.
Slide the drawer bottom
16
into the drawer
sides
14
.
Step 2.3
Step 2.4
Screw the bolts
Cb
into
the holes indicated on
the drawer front
13
.
Step 2.5
Push the drawer front
13
onto the drawer sides
14
.
Place cams
Ca
into the
holes indicated. Arrow
pointing towards the front.
Turn the cams
Ca
to the
right to x the front.
350264-18
17
90°
16
14
14
Cb
ø5 x 8, cc34mm Bolt x 8
13
Cb
Cb
4
x
14
14
Ca
Ca
13
Ca
ø15 x 10.5mm Cam x
8
4x
Fi
Fi
Fi
16
14
14
Fi
15
13
Fi
Back fitting w. ø3.5 x 15mm Screw x
Fi
8
4
x
4
x
