Assembly Instructions
Place the two cup
hinges
Me
into the holes
indicated on the center
door
17
.
Place
the four cup
hinges
Mf
into
the holes indicated
on the outer doors
17
.
Fix the hinges using
screws
Bo
.
Fix the magnet catches
Pd
using screws
Bo
into
the holes indicated.
Step 3.1
Assembly of the doors.
Note !
Two types of hinges is
included. Type
Me
must
be used on the center
door and type
Mf
must be
used on the outer doors.
Step 3
350264-20
19
17
Mf
Bo
Mf
4
ø26mm Cup hinge x
35 x 12 x 1mm Magnet catch x
Pd
6
ø3 x 12mm Screw x
Bo
18
Mf
Bo
Bo
17
17
18
Mf
Me
Me
2
ø26mm Cup hinge x
17
17
Bo
Bo
Bo
Bo
Pd
Me
Me
Bo
Pd
Large
Small
Mf
Bo
Bo
Pd
Bo
Mf
Bo
Pd
Bo
Pd
Bo
Pd
17
Door, left
Door, right
Door, center
Mf
Mf
Me
Door, left
Door, right
Door, center
