Assembly Instructions
Step 5
Attach the Saddle (72) to the Seat
Tube (69) with Nylon Nuts (70) and
Washers (71) provided; Slide the Seat
post Sleeve (74) into the Seat Tube(69),
71
71
71
70
70 70
72
69
74
Step 6:
Insert the Seat Tube (69) with Saddle into
the Main frame (1) and lock at desired
height with Triangle knob (73).
69
73
1
7
