5 Cat.No.: 8180197
G
Use either the extension piece(s) supplied with the gate
and/or 8344816 Cuggl Safety Gate Extension White
(sold separately) to span the width of the opening.
G
GG
Insert steel bolt (G) into the required extension piece(s) in the orientation
as shown above.
For the 12cm & 24cm extension piece(s) insert the shorter
of the two ends of steel bolt (G) into the safety gate. When correctly
assembled there shouldn t be a gap between the safety gate and the
extension piece
.
,
I（1x）
F（1X）
