Argos HOME - Step-by-Step Assembly Guide

Step 1
Assembly Instructions
5
B
C
B
B
x4
Fitting dowels to the
divider panels.
x1
50mm30mm
Step 2
B
B
Fitting dowels to the
shelf panels.
1. Insert 2 of the 30mm
dowels into the pre-
drilled holes in one end of
the divider panel
and 2 50mm dowels
into other end of the
same panel.
2. Insert 2 of the 50mm
dowels into only one
end of 2 of the divider
panels .
3. Insert 2 of the 30mm
dowels into only one
end of the other divider
panel .
Insert 2 of the 30mm
dowels into the pre-
drilled holes in both ends
of the shelf panels .
9098
9098
9097
9098
Step 3
Connect shelf panel
and divider panels.
FINISHED EDGES TO THE FLOOR
Locate the divider panel
which has the 2
50mm dowels inserted
into the pre-drilled holes
in panel .
Slide the 50mm dowels
through the pre-
drilled holes in the shelf
panel and connect
to the next divider panel
B
B
B
B
x12
30mm
C
C
C
C
C
C
C
C
C
C
C
x6
9098
B
B
x1
9098
9098
9098
9098
9097
B
B
x3
B
B
9097
9097
9097
9098
9098
9098
9098
9097
x2
1.
1.
2.
2.
3.
