Argos HOME - Final Steps and Information; Squaring and Securing the Unit

A
A
Assembly Instructions
8
Step 8
Step 9
Fasten the other end
panel to the shelf and
top & bottom panels.
A
x5
9096
9096
9097
9097
9097
9121
A
A
Connect the end panel
to the dowels in
the shelf panels
Secure the end panel
in place by using
screws and screwing
into the pre-drilled holes
in the top/bottom panels
and the central
shelf .
9121
9121
9097
9096
9097
A
Squaring the unit up.
Important.
Ensure a tape
m measure is used
to square unit up!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
DIAG 1
DIAG 2
DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
