10
Check the box and make sure you have all the parts and fittings listed. If not, contact your local store or the
Helpline
0844-335-0229 who will be able to help you.
11
Feed the M6x45 Bolts (D10) through the Washers (D13), the
body, left/right leg and secure with M6 Nuts (D14).
Insert electrode ignition wire through the hole in the left
sidewall of control panel and connect it onto the middle of
ignition pushbutton as shown.
Unscrew a M6 Nut from either M6x55 Bolt.
Connect protective electric wire to left leg
using the bolt and nut as shown.
12
