Check the box and make sure you have all the parts and fittings listed. If not, contact your local store or the
Helpline
0844-335-0229 who will be able to help you.
A. Parts List
Quantities vary according to model purchased. Specifications subject to change without prior notice. For more details on
hardware, please see the corresponding Hardware Reference Diagram for your barbecue model.
CODE PART QTY 3 Burner Stainless Steel with Hood
HOOD
A1 Hood (Pre-assembled to Body) 1
A2 Hood Handle 1
A3 Grill 1
A4 Griddle 1
A5 Flame Tamer 2
A6 Warming Rack 1
BODY
B1 Body 1
B2 Control Panel 1
B3 Ignition Pushbutton 1
B4 Knob 3
B5 Grease Cup Holder 1
B6 Grease Cup 1
B7 Hose / Regulator Assembly 1
TROLLEY
C1 Side Burner Shelf 1
C2 Grid 1
C3 Side Burner Rear Support 1
C4 Side Burner Front Support 1
C5 Side Shelf 1
C6 Side Shelf Support 2
C7 Side Shelf Bracket 2
C8 Rear Support 1
C9 Left Panel 1
C10 Right Panel 1
C11 Front Panel 1
C12 Left Leg 1
C13 Leg Support 1
C14 Right Leg 1
C15 Leg Endcap 1
C16 Axle 1
C17 Wheel 2
C18 Side Shelf Long Pin 1
HARDWARE
D1 Axle Washer 2
D2 Locknut 2
D3 Spring Clip 4
D4 Side Shelf Short Pin 2
D5 ST4.0x10 Screw 2
D6 ST4.0x15 Screw 4
D7 ST4.8x25 Screw 2
D8 M6x20 Bolt 1
D9 M6x40 Bolt 6
D10 M6x45 Bolt 13
D11 M6x50 Bolt 4
D12 M6x55 Bolt 2
D13
Ø6 Washer
15
D14 M6 Nut 15
Pre-Assembled component
