GB-11
MOVING THE UNIT WITH THE ENGINE OFF
IMPORTANT: Never tow unit.
1. Shut OFF engine.
2. Place seat in the service position (See Service Position on
page 13).
3. Turn right and left bypass valve levers counter clockwise
1/2 turn (Figure 5).
4. Disengage parking brake.
5. Push unit to desired location.
6. Engage parking brake.
7. Turn bypass valve levers clockwise 1/2 turn.
FOR BEST PERFORMANCE
Cut grass when it is dry.
Keep mower blades sharp.
Keep mower deck properly levelled.
Adjust anti-scalp rollers to prevent scalping.
Do not set height of cut too low. For very tall grass, mow twice.
Do not travel too fast.
Mow with the engine set at full throttle.
When mulching, only remove 1/3 of grass length per cutting.
Discharge clippings into areas already cut.
Vary cutting pattern with each mowing.
Do not allow grass or debris to collect inside of mower deck.
Clean after each use.
WARNING: Do not bypass transmission when on a
slope.
Figure 5
1. Left Bypass Valve Lever
2. Right Bypass Valve Lever
2
1
OF3371
Front of unit
