TECHNICAL DATA
It is important to consider that the characteristics and technical data stated by the manufacturer refer to the
appliance supplied at the specified mains rated power: 230V 50Hz.
The performance levels and the characteristics of any cooling appliance are noticeably affected by the envi-
ronmental conditions where the Internal and External Units operate. This means that the values measured
(temperature, pressure, electrical consumption, etc.) vary according to the climatic situation.
Cooling Heating
INTERNAL Unit 27°C 50% UR 20°C 60% UR
EXTERNAL Unit 35°C 40% UR 6°C 80% UR
Legend: °C = degrees centigrade UR = relative humidity
N.B.
The technical data in the chart can have variations. You advises to always make reference to the characteristic label on
the air condition
Model
Cooling power
Cooling power
Cooling power
Heat pump heating power
Heat pump heating power
Heat pump heating power
Humidity removed
Cooling electric power 1)
Heating electric power 1)
EER
COP
Energy class cooling
Energy class heating
Voltage - frequency - No. of phases
Cooling rated current 1)
Heating rated current 1)
Max. noisiness internal unit 2)
Max. noisiness external unit 2)
Air flow internal unit (max. speed)
Weight of internal unit
Weight of external unit
7000 9000 12000
frig/h 1797 2287 3104
W 2090 2660 3610
BTU/h 7126
9070 12310
Kcal /h 1874 2322 3182
W 2180 2700 3700
BTU/h 7433 9207 12617
l / h 0,7 1 1,4
W 640
830 1120
W 670
880 1110
W/W 3,26 3,21 3,22
W/W 3,61 3,61 3,41
AAA
AAB
V / Hz / Ph 230 / 50 / 1 230 / 50 / 1 230 / 50 / 1
A 2,78 3,60 4,86
A 2,91 3,82 4,82
dBA 33 35 39
dBA 54 54 55
m
3
/ h 450 550 650
Kg 10 10 1
Kg 29 31 35
