menu table
EN
MENU SUB-MENU PARAMETER
DESCRIPTION RANGE
6 5 3 Temperature adjustment curve
6 5 4 Parallel shifting
6 5 5 Proportional room inuence
6 5 6 Max T
6 5 7 Min T
6 5 8 Target DeltaT for modulation
7 ZONE MODULE
7 1 Manual mode
7 1 0 Manual mode activation ON - OFF
7 1 1 Z1 pump control ON - OFF
7 1 2 Z2 pump control ON - OFF
7 1 3 Z3 pump control ON - OFF
7 1 4 Z2 mixing valve control
0. OFF
1. Open
2. Closed
7 1 5 Z3 mixing valve control
0. OFF
1. Open
2. Closed
7 2 Zone module
7 2 0 Hydraulic circuit diagram
0. Not dened
1. MCD
2. MGM II
3. MGM III
4. MGZ I
5. MGZ II
6. MGZ III
7 2 1 T delivery correction
7 2 2 AUX output function
0. Heat request
1. External pump
2. Alarm
7 2 3 External temperature correction
7 2 8 Pumps overrun time of Z1 Default = 150 sec.
7 3 Cooling
7 3 0 Cooling T Delivery Correction
7 3 1 Zone general parameter
7 3 2 Zone general parameter
7 5
7 5 9 Pumps overrun time of Z2 Default = 150 sec.
