Aritech 2X-AF2-FB-PRT-P Installation Manual

Chapter 3: Configuration and commissioning
112 2X-A Series Installation Manual
Output groups
Select Output groups to configure the control panel output groups. Control panel
outputs must be assigned to output groups for activation.
An output group is a collection of outputs of the same type that activate and
deactivate at the same time (they are commanded simultaneously). Output
groups are identified by the output group number.
Outputs are assigned to the default output groups during autosetup (see
“Autosetup” on page 98).
Up to 300 sounder, fire routing, fire protection, extinguishing, and program output
groups can be configured (depending on group type).
Sounder output groups, fire routing output groups, and fire protection output
groups are controlled (and their status indicated) by the corresponding sounder,
fire routing, and fire protection buttons and LEDs on the front of the control panel.
Program output groups have no associated buttons or LEDs on the front of the
control panel but their status is displayed on the LCD.
The default control panel output groups are shown below.
Note: This option is not available on repeater panels.
Table 58: Default output groups
Group number
Type Description
1
SND [1] Sounder and supervised outputs.
2
SND [1][2] Sounder outputs.
301
PRG Nonsupervised relay outputs. These
outputs are assigned
to this group during autosetup.
801
EXTIN [3] Extinguishing device outputs.
971
FR [1] Fire routing outputs. This group is only available on
control panels with the corresponding fire routing controls.
981
FP [1] Fire protection outputs. This group is only available on
control panels with the corresponding fire protection
controls.
991
ALARM [4] Outputs activated when the control panel is in alarm
status.
992
FAULT [4] Outputs activated when the control panel is in fault status.
993
DIS [4] Outputs activated when the control panel is in disable
status.
994
TEST [4] Outputs activated when the control panel is in test status.
[1]
To comply with EN 54 requirements, this output group must be linked to a programmable
button when any other output group
of the same type is linked to a programmable button.
[
2] NEN 2575 operating mode only.
[
3] Extinguishing output groups are only activated with EN 54 type C alarm confirmation.
[4] These output groups are not configurable.
