Chapter 3: Configuration and commissioning
2X-A Series Installation Manual 111
Table 57: Configurable output types
Description
Select this option for a sounder output
Select this option for a fire routing output
Select this option for a fire protection output
Select this option for program options (see below)
Select this option for an extinguishing output
Select this option for an output that activates when the control panel is in
alarm status
Select this option for an output that activates when the control panel is in
fault status
Select this option for an output that activates when the control panel is in
test status
Select this option for an output that activates when the control panel is in
disable status
To enable or disable a control panel output:
1. Select Field setup from the Main menu.
2. Select Panel I/O configuration.
3. Select Outputs, and then select the output to be enabled or disabled.
Configurable outputs are listed as OUT1, OUT2, etc., the supervised alarm
output is listed as ALM_O, and the supervised fault output is listed as FLT_O.
4. In the Control option, select ENB (enable), DIS (disable), DIS_D (disable in
day mode), or DIS_N (disable in night mode).
5. Press F4 (Enter), and then press F1 (Back).
6. Press F1 (Save), F3 (Apply), F4 (Discard), or F2 (Exit).
Remember to apply saved settings from the Main menu.
Note: Changes to the configuration of a Class A output are applied to all output
pairs used to create the Class A output (OUT1/OUT2, etc.). This includes
enable/disable configuration options. For example, if the OUT1 type is changed
to PRG and Group-n changed to 5, then the configuration of the paired OUT2 is
updated automatically to match these settings.
