Page 32 Installation manual for the CD72/95/15012
Dimensions (l x b x h)
CD 3008/3048
CD 3009/3049
CD 9031
CD 72/95
CD 150
160 x 120 x 35 (3 mm ABS)
160 x 120 x 35 (3 mm ABS)
175 x 125 x 37 (3 mm polycarbonate)
315 x 385 x 88 (1,25 mm steel plate)
475 x 460 x 160 (1,25 mm steel plate)
Output no. Location Output connected max. Zone no.
1 to 5 control panel 100 mA
1 to 8
6 to 17 remotes 40 mA
9 to 24
18 internal siren CD72 1A
n/a
19 external siren CD72 1A
n/a
Table 5. Overview of the inputs and outputs on the CD72
Output no. Location Output connected max. Zone no.
1 to 8 control panel 100 mA (output 8 = 1 A)
1 to 16
9 to 40 remotes 40 mA
17 to 144
41 to 48 expanders 100 mA (output 48 = 1 A)
145 to 152
49 internal siren CD95/150 1A
n/a
50 external siren CD95/150 1A
n/a
Table 6. Overview of the inputs and outputs on the CD95/150
