Arkal Spin Klin - Seasonal Maintenance - Cleaning the Discs

7
Seasonal Maintenance ± Cleaning the Discs
When manual cleaning of the discs is required, please follow the steps described below:
Make sure that system is not under
pressure! Release the clamp and
remove the cover
(Figures 1, 2)
Unscrew the butterfly-nut on the filtration
element (Figure 3)
Remove the tightening cylinder
(Figure 4)
Remove the discs (for convenience
we recommend using a plastic bag)
(Figures 5, 6)
Tie each set on a string and place
them in a cleaning solutions (HCL,
Chlorine, or other) refer to ³Cleaning
Recommendations Clogged Filtration
'LVFV´
Thoroughly wash the discs with fresh
water
(Figure 7)
R
eassemble the discs on the spines,
check that the correct quantities of
discs are assembled on the spine:
when the discs are pressed with two
hands, the top disc should be level
with the imprinted circle on the
outside of the spine
(Figure 8)
Put on the tightening cylinder and
tighten the butterfly-nut, then
reassemble the filter cover and
tighten the clamp
(Figures 9, 10)
Figure 1 Figure 2
Figure 3 Figure 4
Figure 5
Figure 6
Figure 7 Figure 8
Figure 9 Figure 10
