Installation

Note: This fan must be installed by a licenced

electrical contractor

• Improperly installed ceiling sweep fans can

be dangerous and expensive to repair and

will void guarantee. This fan is designed for

indoor use only. Do not mount in positions

where fan is subject to water or moisture.

The fan must be installed so that the blades

are greater than 2.1 metres from floor.

NOTE TO THE INSTALLER:

Please retain this instruction leaflet and give it to the owner for their future reference.

All wiring must comply with the requirements

of Australian Standard AS3000.

• Use only with the controller supplied.

• The fan blades supplied for this fan are

matched to minimise wobble. If installing

more than one fan do not mix blade sets.

Assembly Instructions

Ceiling Sweep Fan

Important! Please read these instructions carefully.

USE AND CARE INSTRUCTIONS FOR THE OWNER BEGIN ON PAGE 5

This picture is of a

CSF120BCL 120cm 4 Blade Fan

Model numbers will vary with different styles. e.g. CSF120BL with oyster style light

CSF Series

CSFseries Instructs 28/7/05 4:56 PM Page 1

Table of Contents

Questions and Answers:

A
Antonio WernerAug 2, 2025
Why Arlec CSF120BCL will not start?
- R
  Robert OsbornAug 2, 2025
  Your Arlec Fan might not be starting due to several reasons: * A blown fuse or circuit breaker. Check both the main and branch circuit fuses or circuit breakers. * Loose power line connections. Inspect the line wire connections to the fan. * The reversing switch is not fully engaged. Ensure the switch is pushed either completely up or down. * The speed controller is not correctly positioned. Verify the speed controller's position.
M
Misty KelleyAug 11, 2025
How to fix noisy Arlec CSF120BCL?
- H
  hernandezoliviaAug 11, 2025
  A noisy Arlec Fan can be caused by several factors: * Loose or rattling light kit glassware. Ensure the brass knob securing the glass is finger tight. * Incorrect bulbs in the light kit. Verify that you are using the suggested bulbs. * Loose fan blade screws. Re-tighten all screws on the fan blades, but avoid over-tightening. * The ceiling fan is not secured against the ceiling. Re-tighten all screws in the hanging bracket or plate. * Incorrect speed controller. Replace the controller with the one supplied and re-tighten the screws on the upper side of the fan motor body.

Arlec CSF120BCL Specifications

General

Brand	Arlec
Model	CSF120BCL
Category	Fan
Language	English

Summary

Assembly Instructions

Installation

Detailed steps for safely mounting and wiring the ceiling fan, including location requirements and secure fixing.

Part Identification

Information for the Owner

Care and Cleaning

Instructions for periodic cleaning using soft materials to maintain finish and prevent damage.

Wobble

Guidance on diagnosing and rectifying fan wobble through blade and bracket adjustments.

Bumps-in-the-night

Explanation of normal operating noises and potential external factors affecting fan sound.

Fan Lights

Information on fan light glass and globes, noting they are typically not covered by warranty.

Summer/Winter Operation

Instructions on using the reversing switch for optimal airflow direction in different seasons.

Arlec Guarantee

Trouble Shooting Checklist

A guide to common fan problems, their causes, and suggested remedies for resolution.

Installation Record Form
