- 47 -
‘COMMANDS’ MENU
„AUTOTEST‟:
press to access autotest mode (See Autotest paragraph for detailed information).
„UNLOCK‟:
if the inverter is locked (Lxx codes), press to force a recovery attempt.
‘SETTINGS’ MENU
„LANGUAGE‟:
Press and the display will read „LANGUAGE‟ on the first line and will show the currently set language on the second
line. Press keys ↑ and ↓ to choose from: „Italiano‟, „Deutsch‟, „Español‟, „English‟, „Français‟.
Whatever language is set and whatever menu you are on, the language settings page can always be
accessed by pressing the ↑ and buttons together. Holding them down for longer than 4 seconds sets
English as the language.
„DATE & TIME‟:
press and the display will show the current date (dd/mm/yy) on the first line and the current time on the second line
(hh:mm:ss S/L). This menu is a copy of the system clock: changing any field stops the progress of this copy (but not the
system clock).
The → arrow indicates the current field: the ↑ or ↓ keys can be used to edit the field and confirms and moves on to the
next field. Keep ↑ or ↓ pressed to scroll quickly through the digits.
Clear the seconds by pressing ↑ or ↓ on the relative field.
Any change to/from daylight saving time can be made by pressing ↑ or ↓ on the S/L field.
Press on the last field of the screen (the S/L field) to automatically return to the „EXIT‟ menu if no change has been
made. If a change has been made, the settings must be confirmed by pressing again, or cancelled by pressing ↑ or ↓.
In any case, you will now return to the „EXIT‟ menu.
The date can also be set from a PC using special software.
„ADDRESS‟:
press and the display will show the current address.
The address on the RS485/422 bus can be set pressing ↑ and confirmed by pressing . Keep ↑ or ↓ pressed to scroll
quickly through the digits. Possible values include:
„AUTO‟: the inverter uses a mechanism of self assignment for the address.
From 1 to 255: fixed address on the bus.
NOTE: If using one of the following cards (inserted into the expansion slot):
XPV2RSA1B NetMan 102 Plus network card
XPV2RMC2A ModBus card
the address of the PV inverter must be set to AUTO (default value).
„NATION‟:
This screen is available for 12 hours subsequent to the initial setting of the nation of installation. During this period, the
installer can correct any error without requesting technical assistance.
Press and the display will read „NATION‟ on the first line and will show the currently set nation on the second line.
Press ↑ or ↓ to change the set nation and to confirm.
'LOW MAINS POWER'
This is the screen for the activation of the "Low Mains Power Power Limitation Function (VPD)”. The inverter limits the
output power in order to avoid raising the mains voltage above the cut-off level set by the Country's regulations.
