Assembly InstructionsStorage Cube
5
Part 1: Main Cabinet
Congratulations and welcome to Arrow Sewing Furniture! We can’t wait to get your brand new Storage Cube up and running.
Please contact our Customer Service Team at 1-800-533-7347 ext. 1 during normal business hours with any assembly related
questions.
G
t1
s1
G
c1
Caster x4
t1
4x16 Screw x16
s1
6x35 Cam Bolt x8
c1
Attach t1 Casters to the underside
of Panel G, securing in place with s1
Screws.
Attach c1 Cam Bolts to the top side of
Panel G.
