Arrow 81100 - Side Panel Preparation; Preparing Side Panels O and O1

Assembly InstructionsStorage Cube
6
Part 1: Main Cabinet
O
O1
F1
6x35 Cam Bolt x4
c1
8x30 Dowel Pin x16
d1
c1
c1
d1
d1
d1
Attach 2 c1 Cam Bolts to Panel O.
Insert 6 d1 Dowel Pins into the edges
of Panel O.
Attach 2 c1 Cam Bolts to Panel O1.
Insert 6 d1 Dowel Pins into the edges
of Panel O1.
Insert 4 d1 Dowel Pins into the edges
of Panel F1.
