Arrow 81100 - Center Panel Preparation; Preparing Center Panel X

Assembly InstructionsStorage Cube
8
Part 1: Main Cabinet
X
X
6x35 Cam Bolt x8
c1
8x30 Dowel Pin x4
d1
NOTE: Both sides of Panel
X must be prepared for
assembly.
Side 1
Side 2
Panel X Side 1:
Attach 4 c1 Cam Bolts
Insert 4 d1 Dowel Pins
Panel X Side 2:
Attach 4 c1 Cam Bolts
