3
Fig.7
Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
Fig.7
Fig.8
a b
Quick release bottom load magazine
Proper firing technique
a: proper flush staple b: not flush staple
Pull out pusher assembly
Place staples in channel, legs up
Place nails on left side of channel, tips up
Place staple into magazine to the left side
of the channel
1
2
