COMMENT CHARGER DES AGRAFES
11
DE NOUVEAU
À L'INDEX
TO LOAD
1. Remove pusher rod from machine by pushing
in and up, then pulling out.
2. Insert strip of staples.
3. Replace pusher rod.
TO CLEAN STAPLE CHANNEL
1. Remove pusher rod “A” and any remaining staples.
2. While squeezing front end of tool “B”. remove pin “C”.
Pin “C” is reversable for right or left handed operation.
3. Pull out entire staple chamber “D” to clean or clear jams.
4. When replacing staple chamber squeeze together as
shown “B” and replace Pin “C”.
