HOW TO LOAD STAPLES
3
BACK TO
INDEX
LOADING STAPLES:
Hold staple gun upside down as shown in fig 1.
Release magazine latch squeeze release and pull open as shown in fig 2.
Pull magazine open as shown in fig 3.
TO LOAD STAPLES… Insert strip of staples into magazine with points up
as shown in fig 4.
Push magazine closed and with finger making sure magazine latches
closed fig 5.
TOLOAD : SQUEESE TRACK RELEASE
P
ULL BACK AND DROP IN STAPLES WITH POINTS UP.
Fig1.
Fig5.
Fig3.
Fig4.
Fig2.
