Metal Handle x4
#8/32x3/4”
Handle Bolts x8
10mm Hex Nuts x8 Washers x8
Drawer Connecting
Bolts x8
Drawer
Cams x8
Assembly Instructions
Norma Jean Sewing Machine Cabinet Page 2
Hardware Included
Tools required
Drawer Stoppers x4
Door Hinge x3
Strike Plate x1
Door Magnet x1
Door Knob x1
Metal Dowels x4
#8x5/16”
Flathead Screws x4
#4x1/2”
Gold Flathead Screws x21
#4x1/2”
Screw x2
#5x5/8”
Bronze Flathead Screw x1
#7x5/8”
Flathead Screw x16
#6x5/8”
Gold Panhead Screws x2
#8x1/2”
Panhead Screws x16
#8x5/8”
Panhead Screws x4
#7/32x1”
Door Knob Bolt x1
Connecting Bolts x25
Cams x25
Drawer Runners x8
10mm Hex Bolt x8
#6x1”
Flathead Screw x32
#10x1-1/4”
Flathead Screw x16
Wood dowel x8
Note: Screws are included in the bag of parts they will be
used with.
*Items not drawn to scale.
Phillips Screwdriver
Wrench 10 mm
Hammer
Electric screwdriver
Plastic Tray Large x1
Tote Tray x1
Plastic Tray Small x3
Left Wing x1 Right Wing x1
Round Magnet x2
Bronze Strike
Washers x2
Seff Sticking
Rubber Tab x2
Locking
Casters x2
Non-locking
Casters x3
Socket Wrench 10 mm
Support Hinge x4
Caster Insert x5 Caster Clips x5
