Assembly InstructionsOLIVIA Sewing Cabinet Page 7
Step 8. With the Cams facing back attach Cabinet
Connector Panel (B) to Side Panels (D) and (L),
guiding the connecting bolts Into the holes on the
Step 9. With two people attach Table Top (A) to the
top of the Cabinets. The handle lever should be on
the right side and facing down when attaching.
FIG. 8.
FIG. 9.
edge of (B) (As shown in FIG. 8) and tightening the
Cams (x4).
180°
Guide Connecting bolts and Wood Dowels into
holes on top edge of cabinets (As shown in FIG. 9).
Tighten all 8 Cams.
180°
To Next Page
